HIGHLIGHTS

  • 5 步向导程序指导您完成操作
  • 单端和差分器件
  • 夹具左右两侧可以是非对称的
  • 直通长度可以指定，或根据开路或短路测量结果确定
  • 通过外推法匹配被测器件频率
  • 功率校正功能可补偿随频率变化的夹具损耗
  • 去嵌入文件可保存为多种格式，以便日后在 PNA、ADS 和 PLTS 中使用
  • 要求 PNA、PNA-L 和 PNA-X 装有 Windows 7 操作系统

许多器件没有同轴连接器，因此在同轴环境中测量时，需要使用夹具将其固定。为了保证 DUT（被测器件）的测量精度，需要精确去除夹具效应。本选件可添加功能强大的向导程序，指导您表征夹具并从测量结果中移除夹具效应。S93007B 相当于 PNA/PNA-L/PNA-X 系列 A 型网络分析仪的选件 007。

Free Trials

  • Get 30-day free trial license
  • Enables software application on your PNA Series
S96007A Automatic Fixture Removal

Interested in a S93007B?

Extend the capabilities for your 自动夹具移除
