Y1270A Front Panel Interfacing Kit for M9018A PXIe Chassis
The Keysight Technologies, Inc. Y1270A front panel interfacing kit for M9018A PXIe chassis provides a rugged interface to the front panel connectors of modules installed in an M9018A PXIe Chassis. The frame comes with a semi-transparent cover for additional protection of front panel cables and connectors.
With the front panel interfacing kit you can select different connectors to customize the frame to meet your solution needs. It can accommodate up to four Type-N RF connectors and up to eight BNC low frequency connectors. The interfacing kit provides all the necessary items for you to protect and customize the interface for your solution.
A. Select Interfacing Frame and Cable Kit
Each option comes with frame shown above, specific cables and connectors for each option shown below.
Step 1. Choose Rack Mounting Accessories
Y1270A-101
Frame and Door Assembly with 2 Type-N and 4 BNC Connectors
Kit includes frame impact cover, door assembly, connector identification labels, screws, hole plugs, 2 Type-N connectors with cables, 4 BNC connectors with cables.
Y1270A-102
Frame and Door Assembly with 4 Type-N and 8 BNC Connectors
Kit includes frame impact cover, door assembly, connector identification labels, screws, hole plugs, 4 Type-N connectors with cables, 8 BNC connectors with cables.
B. Select Rack Mounting Kit
Step 1. Choose Rack Mounting Accessories
Y1270A-301
Rack mount kit: Includes rack flanges, rails & filler panel
