Linear and Switching Power Supply Fundamentals

Linear and Switching Power Supply Fundamentals

eBooks

INTRODUCTION

There are many types of power supplies that you can use in your lab or on the manufacturing line. A power supply’s primary function is to convert a generic supply of electrical energy into a form of energy usable by the device under test (DUT). In the case of a DC power supply, the goal is to convert AC power from the wall into userdefinable DC power.



In this e-book, we look at the basic architecture of the two main types of DC power supplies: linear and switching.

  • A linear supply creates DC power using a transformer to control the output
  • A switching supply uses a transistor switching architecture to control the output Each has its advantages and disadvantages.

Let’s start with a linear power supply

×
