Boost IoT with 5G NR RedCap

The 5G RedCap specification introduces support for wireless devices with reduced 5G capabilities. These devices are less complex, have lower costs, and consume less power, allowing them to address new cellular internet of things (CIoT) use cases such as industrial sensors and wearables. Learn more about how our Wireless Network Emulation solutions can help you perform radio frequency (RF), protocol, and functional testing of devices for RedCap.

Highlights

The Keysight E7515R UXM 5G wireless test solution is a reduced capability hardware test platform optimized for 5G RedCap & Cellular Internet of Things (CIoT) Technologies. Supporting the latest 3GPP 5G New Radio (NR) Release 17 (Rel-17), the E7515R UXM 5G wireless test solution enables you to establish a 5G call with a device under test (DUT) and perform RF, protocol, functional and performance tests to ensure standards-compliance and user experience of the device.

Built on the same hardware architecture as the market-leading E7515B UXM 5G wireless test platform, the E7515R supports the entire device development workflow, from early design and development through acceptance and certification testing, manufacturing, and repair. The E7515R uses the same proven software solutions as the E7515B.

This solution provides comprehensive test coverage in a single unit, including the following capabilities:

  • Protocol, RF and Functional (IP data, Voice, Battery, etc.) testing
  • Rel-17 RedCap (FDD, HD-FDD, TDD)
  • NB-IoT
  • Cat-M1
  • LTE Cat-1 to Cat-4

主要技术指标

其他特性
R17 UL Coverage Enhancements
接口
Baseband IQ
内置端口数量
2 Tx DL + 2 Rx UL RF ports @ 100MHz
技术
FR1 up to 6GHz and FR2-ready
Test environment
Protocol, RF, and Functional (IP data, Voice, Battery) testing
其他特性
接口
内置端口数量
技术
Test environment
R17 UL Coverage Enhancements
Baseband IQ
2 Tx DL + 2 Rx UL RF ports @ 100MHz
FR1 up to 6GHz and FR2-ready
Protocol, RF, and Functional (IP data, Voice, Battery) testing
查看更多
其他特性:
R17 UL Coverage Enhancements
接口:
Baseband IQ
内置端口数量:
2 Tx DL + 2 Rx UL RF ports @ 100MHz
技术:
FR1 up to 6GHz and FR2-ready
Test environment:
Protocol, RF, and Functional (IP data, Voice, Battery) testing
