AresONE-S 400GE

超高密度 16 端口和 8 端口 400GE QSFP-DD 测试解决方案

您是否已经拥有此产品？ 访问技术支持

产品特点

  • AresONE-S 16 端口和 8 端口型号可在单个平台上实现密度极高的测试
  • 一个平台可以为全部 7 种速度提供支持：具有 PAM4 和 NRZ SERDES 的 400/200/100/50/40/25/10GE
  • 线速率流量为 6.4 Tbps，可以选择同步多个机箱来测试 25.6 Tbps 及以上速率的交换平台
  • 使用 IxNetwork 应用软件进行完整的 L2/3 协议仿真
  • 2RU 固定式机箱，可以降低功耗、满足散热要求
  • 提供精简版、基础版、升级版、套件等各种灵活选择，可根据升级要求进行扩展

超高密度 400GE 测试

随着 400GE 被广为采用，8x56Gb/s 电气接口和 PAM4 编码技术变得越来越常见。 当前的大多数交换机 ASIC 都支持这种新 PAM4 调制以及用于低速技术的传统 NRZ 编码，让从 100GE 升级为 400GE 变得更加简单。 在这些平台上测试从 10GE 到 400GE 的全部 7 种速度已经成为新的挑战。 互联网应用的带宽要求推动了测试 3.2、6.4、12.8、25.6 Tbps ASIC 线速率流量的需求。

是德科技扩大其 AresONE 400GE 网络测试平台的范围，可以满足这些不断发展的市场需求。

具有 16 端口密度和 7 种速度的多合一测试平台

AresONE-S 是 AresONE 系列的最新产品，通过相同的 2RU 固定式机箱外形提供增加一倍的密度。 令人叹服的 6.4 Tbps 流量生成能力可以堆叠起来构建吞吐量更大的测试平台，为您提供一个能够随着需求进行扩展、永不过时的测试平台。 它可以在同一平台上测试 7 种速度，每个端口都能支持以下速度。

PAM4 速度：1x400、2x200、4x100、8x50GE

NRZ 速度：2x100、4x50、2x40、8x25、8x10GE

随用随买，灵活满足预算需求

就测试硬件和软件而言，AresONE-S 让您可以视需要进行灵活配置，满足预算需求。 这也是我们既提供 8 端口和 16 端口精简版以及可在现场从 8 端口升级到 16 端口的完整版，又提供从精简版到全性能版机型的原因。 精简版的性能可以用于数据包爆炸和 RFC 基准测试，完整版的性能则非常适合用于测试运营商级别的路由器和交换机，从而验证网络协议的性能和规模。

  • “在为客户打造即时可用的 400GE 生态系统时，不可或缺的一部分工作就是要证明新一代 400GE 光学器件能够提供 3.2 Tb 的速度。 使用成熟的测试系统（如 AresONE）来演示互操作性，对于将 400GE 推向市场非常关键。”

    旭创科技首席市场官莫兆熊

  • “我们通过战略协作提供实现解决方案所需的专业知识。这些解决方案不仅能够满足行业需求，还能支持新一代高速、高密度网络所需的速度。”

    Molex 集团产品经理兼 QSFP-DD MSA 联合主席 Scott Sommers

  • “非常感谢是德科技在我们实现 400G 过程中提供的大力协助。 我们之间的战略合作伙伴关系对于双方的成长非常关键。”

    Arrcus 在领英上发表的文章

  • “我们很高兴与是德科技合作，使用是德科技的 400GE 解决方案来提升 12.8 Tbps TERALYNX 交换机的性能。 “以最高达到 400GbE 的速度实现如此性能非常重要，在我们与客户、系统厂商，以及铜缆和光缆互联生态系统合作伙伴开展协作时，这一优势可以推动 TERALYNX 解决方案成功获得采用。”

    Innovium 产品管理和营销副总裁 Amit Sanyal
