Highlights

是德科技器件电流波形分析仪能够清晰而精确地显示此前无法测量或无法检测的电流波形。

CX3300 系列器件电流波形分析仪由主机和支持动态电流测量的专用传感器组成，能够分析从 100 pA 至 100 A 的电流。它拥有高达 200 MHz 的宽广带宽和 14 位或 16 位的动态范围。它还使您能以 16 位的分辨率测量动态电压。

对于物联网应用，您可以利用其高达 100 dB 的宽动态范围，测量低功率器件（包括休眠和激活两种状态）的电流曲线图，无需使用多台仪器或进行多次测量。

对于移动应用，其宽带宽和低噪声性能使您能够通过同一台仪器，测量 PDN（供电网络或配电网络）的电流曲线图，包括大的冲击电流和小的休眠电流。

对于先进的 NVM（非易失性存储器）器件开发，您可以通过它测量低电平的瞬态电流，其宽带宽和低噪声性能可以显示出器件的真实脉冲响应。

直观而先进的图形用户界面与触摸屏显示器相结合，使您无需学习厚厚的用户手册，便能快速开始进行电流波形测量。

凭借这些此前没有的特性和功能，这些器件电流波形分析仪能够深入分析电流和电压波形，扩大您在更低功率设计方面的优势。

Key Specifications

Find the Model that's Right for You

上一页
CX3324A
器件电流波形分析仪，1 GSa/s，14/16 位，4 通道
CX3324A 是一款具有 14 位或 16 位分辨率的 4 通道主机。其存储器深度和带宽可以分别升级至 256 MSa/s 和 200 MHz，支持数字通道。操作系统支持 Windows 10。
起价
起价
CX3322A
器件电流波形分析仪，1 GSa/s，14/16 位，2 通道
CX3322A 是拥有 14 位或 16 位分辨率的 2 通道主机系列。其存储器深度和带宽可以分别升级至 256 MSa/s 和 200 MHz，操作系统支持 Windows 10。
起价
起价
ellipsis
查看比较所有型号
下一页

Extend the capabilities for your Device Current Waveform Analyzers

软件
查看所有软件
附件
查看所有附件
保修、校准和服务
查看所有服务
支持
查看所有支持

Featured resources for the 器件电流波形分析仪

Data Sheets 2020.01.07

CX3300A Series Device Current Waveform Analyzer

CX3300A Series Device Current Waveform Analyzer

The Keysight 34461A offers a way to get insight into your measurement data without transferring your data to a PC.

2020.01.07

Application Notes 2019.02.12

The CX3300 Unveils Current Waveform Never Seen by Conventional Current Probes

The CX3300 Unveils Current Waveform Never Seen by Conventional Current Probes

The CX3300A enables a wide range of precision current waveform measurements that have been difficult to obtain using a conventional current probe.

2019.02.12

Application Notes 2018.06.03

CX3300 Series Device Current Waveform Analyzer, 7 Hints for Precise Current Measurements

CX3300 Series Device Current Waveform Analyzer, 7 Hints for Precise Current Measurements

This application note explains 7 hints that can be undertaken in order to obtain more favorable current measurement with the CX3300.

2018.06.03

应用指南 2019.01.06

Accelerate the development of Next Generation Non-Volatile Memory

Accelerate the development of Next Generation Non-Volatile Memory

You can accelerate the development of next generation non voltile memory; CX3300 series for visualizing the fast switching characteristics, B1500A for basic IV,CV,pulsed IV and reliability testing.

2019.01.06

User Manuals 2019.12.23

User's Guide for CX1100 Series Accessories for CX3300

User's Guide for CX1100 Series Accessories for CX3300

Describes accessories for the CX3300 series Device Current Wavefom Analyzer.

2019.12.23

Application Notes 2019.02.17

Non Volatile Memory Devices – Current Waveform Measurements

Non Volatile Memory Devices – Current Waveform Measurements

See how the Keysight CX3300 enables you to easily and accurately visualize true transient current waveform of non volatile memory devices and materials.

2019.02.17

User Manuals 2021.04.25

User's Guide for CX3300 Series Device Current Waveform Analyzer

User's Guide for CX3300 Series Device Current Waveform Analyzer

Describes the front panel operation, installation, and functions of Keysight CX3300 Series Device Current Waveform Analyzer

2021.04.25

查看所有资源

查看所有资源

Related Products

N2787A 3D Probe Positioner

N2787A 3D Probe Positioner

Achieve stable 3D probe positioning for hard-to-reach XYZ access with this flexible articulating arm

N2843A Passive Probe, 10:1, 500 MHz, 1.2 m

N2843A Passive Probe, 10:1, 500 MHz, 1.2 m

Features a high input resistance of 10 MΩ; can be adjusted for low-frequency and high-frequency compensation
