特点

在单个实例中切换多个高压通道

作为高密度开关矩阵，M9120A 可在单个实例中对多个通道进行更高电压的开关切换。 这个 2 线开关矩阵提供了经久耐用的电枢开关，能够同时连接多个通道且每个通道的功率高达 60 W。

  • 将多台仪器连接到多个点，实现自动化测试
  • 经久耐用的 60 W 电枢开关
  • 4 线宽总线
  • 经久耐用的连接器模块或标准电缆连接
  • 4x32 大功率、2 线矩阵
  • 100Vrms
  • 2 A 开关/承载电流
  • 60 W 最大功率
  • 软件驱动程序：Visual Studio、C、C++、C#、Visual Basic、MATLAB 和 LabVIEW

主要技术指标

下载技术资料
Inputs/Outputs
0 - 50 Volts
51 - 125 Volts
模块类型
Matrix
Number of Channels
128 channels
Switch Type
Matrix Switch
Inputs/Outputs
模块类型
Number of Channels
Switch Type
0 - 50 Volts
51 - 125 Volts
Matrix
128 channels
Matrix Switch
查看更多
Inputs/Outputs:
0 - 50 Volts
51 - 125 Volts
模块类型:
Matrix
Number of Channels:
128 channels
Switch Type:
Matrix Switch

标准配置

Prev
PXI 矩阵开关：4x32，2 线，100 Vrms/2 A，电枢继电器

应用

  • 将多台仪器连接到多个点，实现自动化测试

功能

  • 4x32 大功率、2 线矩阵
  • 100Vrms
  • 2 A 开关/承载电流
  • 60 W 最大功率

性能特征

  • 经久耐用的 60 W 电枢开关
1
PXI Matrix Switch: 4x34, 2-wire, 125VDC/2A, EM Relays | KeysightCare Assured First Year Support. | Software and Product Information on CD | Return to Keysight Warranty - 1 year.
1
KeysightCare Assured - Extend to 3 years (includes Return to Keysight Extended Warranty).
起价
Next
M9120A PXI Matrix Switch

想要深入了解 M9120A？
