Generating a Dynamic Gain Model of a Power Amplifier in ADS and using it in SystemVue
应用文章
This How-To application note serves as a guide to generating a Dynamic Gain (DG) model from a DPD Explorer simulation of a Power Amplifier (PA) schematic within Advanced Design System (ADS). The extracted DG model is then re-simulated in a SystemVue simulation. The DG model is a modeling technique invented by Keysight (Jan Verspecht).
