Column Control DTX
E3662B 2.0m Rack Cabinet (41U)

E3662B 2.0m Rack Cabinet (41U)

技术资料

 House your Keysight Technologies, Inc. test and measurement instruments efficiently, securely and attractively

The E3662B is a 2.0 m, quartz gray rack cabinet. It is pre-assembled, competitively priced and has many standard features.

Features

  • Quartz gray color
  • 42U EIA vertical rack space
  • Vented, lockable rear door
  • Removable side panels
  • 13-gauge, cold-rolled welded steel columns
  • Vented top
  • Solid base
  • Leveling screws
  • Retractable anti-tip foot
  • Four concealed lift hooks, each hook can support 227 kg (500 lbs)
  • One pair of system II rails
  • 3-inch, heavy-duty casters
  • Shipping cost included in price
  • Ability to move and ship fully integrated up to 1,000 lbs
  • Racks come fully assembled and ready for equipment installation

 Specifications

  • Material: Cold-rolled steel
  • Weight: 177 kg (390 lbs)
  • Color: Quartz gray
  • Integrated shipment load capacity: 454 kg (1000 lbs)
  • Total load capacity: 816 kg (1800 lbs)
  • Height: 2020 mm (79.5 in)
  • Width: 600 mm (23.6 in)
  • Depth: 905 mm (35.6 in)

 Installation

This rack is delivered pre-assembled with all standard features.

Tools required for setup:

  • T25 torx screwdriver, for removal of stabilizing shipping panels and rear door L-shaped slam guard.
  • Adjustable wrench or 9/16 in crescent wrench, for removal of rack from the pallet.

Standards

Conforms to the Electronic Industries Association (EIA) standard 310-D. It is a type A cabinet with 14U of vertical mounting space. One ‘U’ is equal to 44.45 mm (1.75 in).

What changed

Replaces: E3662A

  • Color changed from parchment white to quartz gray

×
