TestJet and VTEP Hardware Description and Verification

TestJet and VTEP Hardware Description and Verification

应用文章

This chapter describes the TestJet and VTEP hardware components and the required connections for assembly on test fixtures.

  • There are 64 ports on two connectors, J2 and J3, on the MUX card (port 1 to 32 on J2 and port 33 to 64 on J3)
  • The first row of the connectors are signals and the second row belongs to ground
  • The ports are configured in columns; each port consists of signal and ground connections to the AMP board

×
