Sample more signals, faster and dynamically
Get the next-generation data acquisition (DAQ) system with a three-slot mainframe and your choice of nine plug-in modules. The Keysight DAQ970A / DAQ973A DAQ system has high-quality switching and an advanced built-in 6½-digit multimeter that allows you to measure fast and accurately.
DAQ970A / DAQ973A DAQs offer these features:
• fastest reading measurements — up to 50,000 readings / sec — and scan rates up to 450 channels / sec
• ability to measure very low current ranges (1 μA DC and 100 μA AC) and very high resistance range (1,000 MΩ)
• auto-calibration that compensates for internal drifts caused by time and temperature changes
• 3497XA-compatible, program and configuration
• onboard temperature reference
• LAN and USB for easy PC connectivity (DAQ973A includes additional GPIB)
Technical overview |
DAQ970A |
DAQ973 |
Module slots available |
3 |
3 |
Measurement resolution |
22 bits |
22 bits |
Types of measurements |
• capacitance and diode test • temperature with thermocouples • RTDs and thermistors • DC / AC volts • 2- and 4-wire resistance • frequency and period • DC/ AC current • direct strain and bridge strain |
• capacitance and diode test • temperature with thermocouples • RTDs and thermistors • DC / AC volts • 2- and 4-wire resistance • frequency and period • DC/ AC current • direct strain and bridge strain |
Connectivity |
• USB 2.0 • built-in LAN • BenchVue / TestFlow • LXI-compliant • USB flash memory drive • USB data logging and data mirroring • remote web interface |
• GPIB • USB 2.0 • built-in LAN • BenchVue / TestFlow • LXI-compliant • USB flash memory drive • USB data logging and data mirroring • remote web interface |
Modules for DAQ970A and DAQ973A systems
A complete selection of plug-in modules gives you a choice of high-quality measurement, switching, and control capabilities. Mix and match modules to get the functionality you need right now. Modules for the DAQ970A / DAQ973A make testing easier, faster, and more reliable. Buy only what you need — and add more modules as your application grows.
Module number |
Description |
Speed (ch / sec) |
Max (volts) |
Max (amps) |
DAQM900A |
20-channel solid-state multiplexer |
450 |
120 V |
0.02 A |
DAQM901A |
20-channel multiplexer (2/4-wire) module |
80 |
300 V |
1 A |
DAQM902A |
16-channel multiplexer (2/4-wire) module |
250 |
300 V |
50 mA |
DAQM903A |
20-channel actuator / GP switch module |
120 |
300 V |
1 A |
DAQM904A |
4 x 8 two-wire matrix module |
120 |
300 V |
1 A |
DAQM905A |
2 GHz dual 1:4 RF mux, 50 Ω module |
60 |
42 V |
0.7 A |
DAQM907A multifunction modules |
Two 8-bit digital I/O ports |
|
42 V |
400 mA |
26-bit event counter |
|
42 V |
|
|
Two 16-bit analog outputs |
|
±12 V |
10 mA |
|
DAQM908A |
40-channel single-ended multiplexer module |
100 |
300 V |
1 A |
DAQM909A |
4-channel simultaneous sampling module |
800 |
36 Vpk |
|
×
